Protech 40″ - 65″ Full Motion TV Wall Mount - FL504
Model # : FL504
Protech Full-Motion TV Wall Mount for 40″-65″ TVs - FL504
| Specifications | |
|---|---|
| TV Sizes: | 37 to 65″ |
| Weight Capacity: | 50 kg / 110 lb |
| Motion Type: | Full-Motion |
| Tilt Angle: | ± 15° Up/ Down |
| Swivel Angle: | ± 90° Left-Right |
| Distance from Wall to TV: | 9.9 cm to 65.0 cm / 3.9 to 25.6 in |
| Level Bubble Meter: | Yes |
| Mounting Wall Studs Required: | 2 |
| 16″ Stud Spacing: | Yes |
| 24″ Stud Spacing: | No |
| Wall Plate (Length x Width): | 45.5 x 16 cm / 17.9 x 6.3 in |
| Height of TV Bracket Rails: | 42.5 cm / 16.7 in |
| Physical Color: | Black |
| Materials: | Solid Steel |
| Shipping: Dimensions (Length x Width x Height) | 55 x 18 x 9 cm / 21.7 x 7.1 x 3.5 in |
| Weight: | 6.5 kg / 14.3 lb. |
| Wall Mounting Hardware: | Yes |
| Assembly Instructions: | Yes |
